Nominal Voltage | 12.8V | |
Nominal Capacity | 100Ah | |
Nominal Energy | 1280Wh | |
Dimension (L * W * H) | 326*173*215 mm | |
Approx. Weight | 11kg | |
Terminal | M8 | |
Cycle Life |
≥3000 Cycle @80%DOD, at 25°C
|
|
Months Self Discharge |
≤3% per month at 25°C
|
|
General | ||
Charge
|
Charge Voltage
|
14.6+0.2V Calculated according to 3.65V voltage of each cell
|
Recommend Charge Current | 0.2C | |
Max. Charge Current | 0.5C | |
Discharge
|
Max. Continuous
Discharge Current
|
1C
|
Peak Discharge Current
|
2C (<3S)
|
|
Discharge Cut-off Voltage
|
10.0V Calculated according to 2.5V voltage of each cell
|
|
Temperature
|
Charge
|
0°C to 45°C (32°F to 113°F) @60±25% Relative Humidity
|
Discharge
|
-20°C to 60°C (-4°F to 140°F) @60±25% Relative Humidity
|
|
Storage
|
15°C ~ 35°C (Please charge and discharge your battery every month)
|
|
Parallel Connection
|
Support 4pcs in Parallel
|
|
Serial Connection
|
Support 4pcs in Series
|
|
Note
|
||
Series and Parallel connections DO NOT recommended at the same time | ||
If need serial connection, please check whether the model support
|
